Renzo® Vanguard
Tactile Ground Surface Indicators

Renzo® Vanguard

AS 1428.4.1AS 1428.1AS 4586NCC 20225-Year Warranty
Australian Made
Proudly
Australian Made

The infrastructure-grade tactile tile. Vanguard's large 300×600mm format halves the joints of a standard tile layout, and its UV-stabilised polymer holds colour and contrast in full sun, built for the exposed, high-traffic environments that fade lesser tiles: transport interchanges, stadium surrounds, civil works. Black, White and Yellow, in Warning and Directional patterns. Tested to AS 4586; designed to AS 1428.4.1.

Luminance contrast required
30%
Minimum against the adjoining surface. Pick the tactile colour from the scale below.
Slip rating
P5
Wet pendulum, AS 4586. Highest of the five classes.
Government Road Authority Approved
VicRoads approved Main Roads Western Australia approved Government of South Australia, Department for Infrastructure and Transport approved
Colour
Configuration
$52.00 / each, ex GST
Tile Calculator area → tiles required
…
300×600mm tiles · ~5.6 tiles per m²
5-year warrantyManufacturing defects, normal use
P5 slip ratingWet pendulum, AS 4586
Supply & installVIC / SA / WA
Specifications
Colour & luminance
Darker · low LRVLuminance reflectance valueLighter · high LRV
0
25
50
75
100
Black
1.36
Yellow
63.23
White
81.98
Black1241111.361.85 wet
Yellow12411863.2363.72 wet
White12411481.9881.43 wet
Mean dry LRV plotted, from the Renzo® Vanguard product data sheet; wet values listed alongside. AS 1428.4.1 requires a minimum 30% luminance contrast against the adjoining surface, so the finish must be chosen against the actual floor, not in isolation.
Applicable Substrates
StoneConcreteMasonryTimberAsphaltExposed Aggregate Don’t see your substrate? Contact us
Downloads
Product Data Sheets
PDFRenzo® Vanguard Integrated Directional - Product Data Sheet114 KBDownload ↓PDFRenzo® Vanguard Integrated Warning - Product Data Sheet143 KBDownload ↓
Test & Compliance
PDFRenzo® Vanguard - Slip Resistance (P-rating, AS 4586)33 KBDownload ↓
CAD & BIM
RFARenzo® Vanguard - BIM File1.9 MBDownload ↓
Configure & Quote this product →
Trade Resources · Restricted Access

Slip Resistance Reports, Sample Warranty Certificates, and Installation Specifications. Available to registered builders, architects, surveyors and specifiers. Access granted within 24 hours of request.
