AS 4586Venturi® Polymer

Stair Nosing

Venturi® Polymer

Name: Venturi® Polymer
Brand: Korb

AS 4586AS 1428.1NCC 20225-Year Warranty

Polymer nosing with replaceable inserts in eight colours, six profile types and five nosing colours, with custom colour available on both. Colour-matches the Renzo® tactile range, so stairs and TGSI read as one palette decision rather than two compromises. Tested to AS 4586; designed to AS 1428.1.

Profile Type · SM

Insert Colour · Black

Nosing Colour · Silver

Searching...

$… / m, ex GST

Piece Specifications

Length (mm)

Qty

5-year warrantyManufacturing defects, normal use

P5 slip ratingWet pendulum, AS 4586

Supply & installVIC / SA / WA

Specifications

LRV contrast

≥ 30%

LRV · Black

2.93 / 2.59

LRV · Charcoal

8.62 / 8.54

LRV · Grey

42.72 / 42.00

LRV · White

73.22 / 72.76

LRV · Blue

7.84 / 7.23

LRV · Red

15.05 / 14.89

LRV · Orange

31.84 / 30.57

LRV · Yellow

54.68 / 53.99

Slip rating

Standard

AS 4586 · AS 1428.1

Warranty

5-Year Product Warranty, covers manufacturing defects under normal use conditions. Full terms available on request.

Applicable Substrates

StoneCeramicConcreteMasonryTimberVinylCarpet TileVinyl TileCarpet with UnderlayBroadloom Carpet Don’t see your substrate? Contact us

Downloads

Product Data Sheets

↓Venturi® Polymer Surface Mounted - Product Data Sheet342 KBPDF ↓Venturi® Polymer Surface Mounted (L) - Product Data Sheet275 KBPDF ↓Venturi® Polymer Recessed - Product Data Sheet365 KBPDF ↓Venturi® Polymer Flooring Tile - Product Data Sheet383 KBPDF ↓Venturi® Polymer Flooring Tile (L) - Product Data Sheet268 KBPDF ↓Venturi® Polymer Carpet with Underlay - Product Data Sheet314 KBPDF

Test & Compliance

↓Venturi® Polymer - Slip Resistance (P-rating, AS 4586)35 KBPDF

CAD & BIM

↓Venturi® Polymer - CAD Detail (section)45 KBDXF ↓Venturi® Polymer - CAD Detail Sheet122 KBPDF

Configure & Quote this product →

Trade Resources · Restricted Access

Slip Resistance Reports, Fire Test Reports, Sample Warranty Certificates, and Installation Specifications. Available to registered builders, architects, surveyors and specifiers. Access granted within 24 hours of request.

Request Access →
